HD12s/HD12L  |   HD24s/HD24L

Sharing the same construction materials as our MES Marine Series units the Cruise N Comfort HD Series 12 Volt split system air conditioners are built with 300 Series Stainless Steel components and hardware making them perfect for use in harsh environments and are built to last. These 12 Volt Air Conditioners are extremely efficient because they operate directly from batteries and utilize Sequential Compressor Technology to reduce current draw from the compressor and the blower motor at times when max cooling is not required. A large external remote condenser mounts to the outside of the area to be cooled and the unit is fitted with R 134a automotive style service ports to make the initial charge and future servicing easy. Our HD Series Systems are a great alternative to retro fitting engine mounted compressors or adding additional cooling to anemic factory air conditioning. The optional thermostat makes it a great no-idle solution for semi trucks or small Rv’s. Why spend thousands more when our products are built from the highest grade components are hand assembled and delivered factory-direct.

HD


Specifications:
HD-12 s/L and HD-24 s/L

Cool only
Available in 4 configurations:
12 Volt
HD-12s 5K BTU/h

Below shows our power consumption with our optional thermostat that utilizes our Sequential Compressor Technology :

 High Blower Speed   38 nominal amps @ 12.8 Volts DC

Medium Blower Speed 32 nominal amps @ 12.8 Volts DC

Low Blower Speed (Whisper Mode) 29 nominal amps @ 12.8 Volts DC



HD-12L 8K BTU/h

Below shows our power consumption with the optional thermostat that utilizes our unique Sequential Compressor Technology :

 High Blower Speed   49 nominal amps @ 12.8 Volts DC

Medium Blower Speed 47 nominal amps @ 12.8 Volts DC

Low Blower Speed (Whisper Mode) 42 nominal amps @ 12.8 Volts DC




24 Volt
HD-24s 7 k BTU/h

Below shows our power consumption with the optional thermostat that utilizes our unique Sequential Compressor Technology :



High Blower Speed  21 nominal amps @ 25.8 Volts DC

Medium Blower Speed 17 nominal amps @ 25.8 Volts DC

Low Blower Speed (Whisper Mode) 14 nominal amps @ 25.8 Volts DC



HD-24L 10k BTU/h

Below shows our power consumption with the optional thermostat that utilizes our unique Sequential Compressor Technology :

 High Blower Speed  33 nominal amps @ 25.8 Volts DC

Medium Blower Speed 29 nominal amps @ 25.8 Volts DC

Low Blower Speed (Whisper Mode) 25 nominal amps @ 25.8 Volts DC



*Blower Duct Size: 4" top exhaust option available

*HD Series  includes 7 feet of  refridgerant lines with fittings.

*Run time of up to 8-10 hours based on 4 Deep Cycle AGM Batteries and depending on ambient temperature, truck insulation and solar load.

*Optional Thermostat Shown

Dimensions:
Evaporator Inside Size: L 22" x W 12" x H 10,5"
Evaporator Weight approx. 62 lbs
Outside Single Fan Condenser 14 " tall x 20"wide x 4 1/2" thick
Warranty: 2 year Parts and 1 year Labor
